AT HOME · NO-SPEND STEM · EXPLORATION

The 25-Minute Family Foil-Boat Load Lab: Change One Shape, Count the Washers

Two equal foil sheets. One changed shape. Identical washers added one at a time. If the family changes everything at once, it built two boats but learned almost nothing.

The blunt version

Making a foil boat that holds random coins is fun. Making two equal foil boats, changing one shape and testing with the same load is an experiment. NASA education material uses a container of water, aluminum foil and small masses or coins to explore floating boats. This family version tightens the method: equal foil area, identical washers, the same tub, the same loading rule and three trials per shape.

The goal is not “win with the biggest number.” The goal is to write a defensible sentence: “In our six tests, shape B held more washers before water crossed the rim because…” The last word can stay uncertain.

Supplies

• Two equal sheets of ordinary aluminum foil for the first pair, plus equal replacement sheets for repeat trials.
• A shallow clear plastic tub with enough water for the boats to float without touching bottom.
• A towel beneath the tub and another towel for hands and spills.
• At least 20 identical large washers, counted by an adult before and after. Use a larger uniform substitute if small parts are unsafe in the household.
• Paper and pencil for the six-test card.
• A ruler only if the child wants to document starting dimensions; no cutting is required.

No app, scale, stopwatch, branded kit or special foil is necessary. Keep phones and chargers out of the splash zone.

The 25-minute run

1. Set the rule—3 minutes: decide that failure occurs when water crosses the rim, the boat tips, or the bottom touches the tub. Use the same rule for every trial.
2. Build shape A—4 minutes: form a simple boat from one foil sheet. Measure only if the family can do so without turning setup into homework.
3. Test A three times—5 minutes: place washers one at a time near the center, alternating sides as the load grows. Record the last count completed before failure. Use a fresh equal sheet and the same shaping method for each trial.
4. Change one feature—3 minutes: make shape B wider, deeper or differently cornered. Do not change foil area and load type too.
5. Test B three times—5 minutes: repeat the exact placement and failure rule.
6. Read the evidence—3 minutes: order each shape’s three counts and use the middle value. The middle result prevents one odd splash or crooked washer from owning the conclusion.
7. Cleanup—2 minutes: count washers, drain the tub with adult control, dry the floor and recycle clean foil if local rules accept it.

Why shape matters without overclaiming

An object floats when the upward buoyant force from displaced water balances its weight. NASA’s Glenn Research Center explains buoyancy through the weight of displaced fluid. A solid piece of aluminum sinks because its material is denser than water; shaped foil can enclose air and spread its total mass across a larger water-displacing form. As washers are added, the boat sits lower and displaces more water. When the rim lets water in, the system changes fast.

That does not mean “wider always wins.” Tall sides can add reserve before the rim floods, but a narrow tall boat may tip. A very wide shallow boat may be stable but have little freeboard. Wrinkles, tiny tears, uneven loading and rebuilding differences all affect the result. The lab gives evidence for these boats under this rule—not a universal best hull.

Questions that improve the second round

• Did the boat fail by tipping, flooding over the rim or leaking through a fold?
• Were washers placed at the same pace and pattern?
• Did shape B really change only one feature?
• Which trial was the odd one, and what visible event might explain it?
• Would a different result appear with a larger tub or a slower loading method?

Choose only one follow-up. The family can test centered versus evenly distributed load with the same shape, but that is a new experiment and needs a new card.

Safety and cleanup boundaries

Adults supervise water and all loads. Do not use the tub on stairs, a wobbly surface or near power strips. Wipe spills immediately. Foil edges can become sharp when torn or crushed; adults inspect and discard damaged material. Count every washer before and after. Keep small parts away from younger siblings, pets and anyone who mouths objects. Do not use lead fishing weights, batteries, magnets, medication, food that will be eaten, or valuable coins.

This activity does not teach real boat stability, life-jacket rules or water rescue. Children need direct adult supervision around any water, including shallow tubs. Empty the tub when finished.

Bad-weather, low-energy and no-water versions

Bad weather: this is already an indoor backup. Keep it away from storm-related leaks or power hazards. Low energy: build one boat, predict the load, run one supervised test and record the failure mode. Do not call that a comparison. No safe small loads: use identical large plastic blocks counted by an adult. No water today: use equal foil sheets to build two freestanding trays, then predict which will float lower; save testing for another day. Child hates wet textures: the child can record while an adult loads.

For a dry measurement activity, use the room measure-and-draw plan. For another controlled family build, try the paper-bridge load test. The flashlight shadow lab works when water is a bad fit.

Who should skip it

Skip this activity if water near the available workspace is unsafe, the household cannot secure the loads, a child cannot resist mouthing materials, or cleanup stress will outweigh the experiment. Skip the three-trial method for a child who only wants open-ended building; let them build without pretending it produced controlled evidence.

Sources and editorial method

Reviewed October 31, 2026 using NASA’s official Aeronautics With You When You Fly educator guide, which includes a floating-boats experiment with water, foil and small masses, and NASA Glenn Research Center’s buoyancy and Archimedes’ principle explainer. The 25-minute sequence, equal-sheet rule, six-test card, middle-result method and safety boundaries are independent editorial adaptations—not NASA instructions, a curriculum endorsement or proof of a hull design. No affiliate links are attached. Report corrections through About.
